核心活儿参数指标 Main Technical Parameters

机型 Model	CLFJ-B1000	CLFJ- B1300	CLFJ-B1600
卷材宽度 MAX.Parent Web Width	1000mm	1300mm	1500mm
放卷直径 Max.parent Web Diameter	Φ800mm	Φ800mm	Φ800mm
收卷直径 Max.Rewinding Diameter	Φ300mm	Φ300mm	Φ300mm
速率 Max.Machine Speed	10-150m/min	10-150m/min	10-150m/min
定长精度 Fixed length accuracy	±5mm	±5mm	±5mm
总功率 Total Power	3KW	3.5KW	4.5KW
分量 Machine Weight	1000kg	1200kg	1500kg
形状尺寸 Overall Dimensions 任务电压 Working Voltage	2600×2000×1600mm      二相220V50HZ	2600×2200×1600mm      二相220V50HZ	2600×2500×1600mm      三相(xiang)380V50HZ
纸芯规格 Paper core specification	25mm, 38mm,50mm等 (or according to your requirement)

好用大规模此机第一广泛用于以及纸材，纸塑和好类，膜类等装潢知料和木箱知料的复卷修边分切机。

机器及的特色 1.远程服务器接纳孩子伺服电机定长上料，在高速公路加载中坚定不移高计算精度。2.PLC触感屏自动地计米，米数自动地设制。3.圆刀/直刀纵切废边活跃排放物裝配。4.自动式自主的上料机，收、放护符配气胀轴。5.拒绝掐断、停车同时放松设计，预送推断出收秘药再持继收料等功能。

Scope of application

This machine is mainly used for re-winding and trimming of various papers, paper-plastic composites, film and other decorative materia🤡ls as 🍰well as packaging materials.

Performance and characteristics

1. This machine adopts servo fixed length feeding to maintain high precision during high speed operatꦺion.

2. PLC touch screen automatically counts meters, meters are autom🔯🐬atically set.

3. Round knife / straight knife slitting 🅷automatic waste discharge device.

4. Pneumatic automatic feeding, receiving and discharging reels with air expansion shaft🤪.

5. Automatic cutting, free parking time setting, pre-feeding to rewind a💟nd continue to receive materials.
