同用大小该机型核心用到常见纸制品，纸塑塑料类，膜类等装潢资科和包装箱资科的复卷修边模切。

性能及标志性 1.该设备悦纳自己系列伺服定长给料，在高速的启动中贯彻高高精准度。2.PLC触摸式屏相互计米，米数相互设计。3.圆刀\\\\\\\\直刀纵切废边自觉摆放零件。4.气动弹簧式自觉送料，收、放法杖配气胀轴。5.积极主动中断、智能停车是轻易制定，预送推断收护符再维持收料等营养价值。Scope of applicationThis machine is mainly used for re-winding and trimming of various papers, paper-plastic composites, film and other decorative materials as well as packaging materials.

Performance and characteristics1. This machine adopts servo fixed length feeding to maintain high precision during high speed operation.2. PLC touch screen automatically counts meters, meters are automatically set.3. Round knife \\\\\\\\ straight knife slitting automatic waste discharge device.4. Pneumatic automatic feeding, receiving and discharging reels with air expansion shaft.5. Automatic cutting, free parking time setting, pre-feeding to rewind and continue to receive materials.

首要手艺参数 Main Technical Parameters

机器 Model		CLFJ-B1000	CLFJ- B1300	CLFJ-B1600
自粘卷材参数 MAX.Parent Web Width		1000mm	130mm	1600mm
放卷直徑 Max.parent Web Diameter		Φ800mm	Φ800mm	Φ800mm
收卷孔(kong)径 Max.Rewinding Diameter		Φ300mm	Φ300mm	Φ300mm
强(qiang)度 Max.Machine Speed		10-150m/min	10-150m/min	10-150m/min
定长精(jing)密度Fixed length accuracy		±5mm	±5mm	±5mm
总(zong)效率 Total Power		3KW	3.5KW	4.5KW
重量 Machine Weight		1000kg	1200kg	1500kg
线条尺寸规格 Overall Dimensions 日(ri)常任(ren)务电阻 Working Voltage		2600×2000×1600mm 二相220V50HZ	2600×2200×1600mm 二相220V50HZ	2600×2500×1600mm 三相380V50HZ
纸芯技术参数Paper core specification	25mm, 38mm,50mm等(deng) (or according to your requirement)
