有机物声明函 同用规模化 机器混用于常见巨型型sbs防水的模切机,如30g/m2-300g/m2牛皮革纸、白夹纸、淋膜纸、铝泊、PVC塑料材质、编织而成袋、锡纸等sbs防水的模切机、复卷等。 身体机能及自己的特色 1. 该机型包容异步交流伺服电机有限公司(失量有限公司)规范、主動锥度弹力,后面卷取体例。主机设备包容直流变频可控硅调压,持续减慢下类衡工作。 2. 主动的计米、提醒功能主治。收卷接受A、B气胀轴调整布局,卸装使用连锁便利店。 3. 放卷辨别是非光电材料分手后纠偏改进装修标准,使不黄金法则姿料能普遍分割。 4. 圆刀纵切废边主动的排放量配备。5. 液压式主动的放料,配气胀轴。6.导轨式分手后上下料零件。也可一侧翻过来卸料!product manualScope of applicationThis machine is suitable for the slitting of various super-large coils, such as slitting and rewinding of 30g/m2-300g/m2 kraft paper, white cardboard, coated paper, aluminum foil, PVC plastic, Woven bag, tin foil and other coils.Performance and characteristics1. The machine adopts asynchronous servo motor (vector motor) control, automatic taper tension and center winding method. The main engine adopts frequency conversion speed regulation to maintain balanced operation during acceleration.2. Automatic metering and alarm function. The winding adopts the A and B air expansion shaft structure, and the unloading operation is convenient.3. Unwinding adopts photoelectric automatic correction correction system to make irregular materials cut normally.4. The circular knife cuts the waste side automatic discharge device.5. Hydraulic automatic feeding, with air expansion shaft.6. Rail type automatic cutting device. The unloading can also be opened unilaterally! 关键一技之长性能:Main Technical Parameters
| 机种 Model | CLFQ-W800 | CLFQ-W1300 |
| zui大原料高度MAX. Width of raw material | 800mm | 1300mm |
| zui大放卷的直径Max.parent Web Diameter | Φ1400mm | Φ1400mm |
| zui大收卷直径为Max.Rewinding Diameter | Φ1100mm | Φ1100mm |
| zui高机械速率单位 Max.Machine Speed | 10-400m/min | 10-400m/min |
| 总热效率 Total Power | 22KW | 25KW |
| 量用 Machine Weight | 4000kg | 4800kg |
| 的样子尺寸大小 Overall Dimensions | 2500×2900×2000mm | 3000×2900×2000mm |
| zui小模切厚度 Min.Slitting Width | 50mm |
|
可以终产物需求 相当制造极品装备。Can be made according to the product requires special equipment. 延长至来关头词:编织方法袋内阀膜模切机,阀口袋怪兽火红膜模切机
