重要性活儿运作：Main Technical Parameters

机型 Model	800	1000	1200
卷材宽度 MAX.Parent Web Width	750mm	950mm	1150mm
放卷直径 Max.parent Web Diameter	Φ800mm	Φ800mm	Φ800mm
收卷直径 Max.Rewinding Diameter	Φ520mm	Φ520mm	Φ520mm
速率 Max.Machine Speed	0-180m/min	0-180m/min	0-180m/min
总功率 Total Power	4KW	5.5KW	5.5KW
分量 Machine Weight	2000kg	2300kg	2600kg
形状尺寸 Overall Dimensions	2800×2400×1200	2800×2600×1200	2800×2800×1200
纸芯规格 Paper core specification	圆刀Round Blade :3mm	直刀Razor Blade :3mm

可可以依照有机物标准 定制配置。

Can be made accoꦗrding to the product requir🍸es special equipment.

好处： 表层卷取复卷模切机机混用于铝泊、原纸、绝缘层知料、烫金字膜、塑胶透气膜（BOPP、PET、PE、PVC）等窄幅分条复卷上海特色：1、放卷还配有光电技术主動纠编配备、磁粉制动踏板器主動表面张力2、配备有及时计米、及时停止设备运转加装3、服务器变频器调压 4、收卷二只磁粉聚散器与冷水机连动规范其中卷取与样貌打丈完全相同，双轴连缀收卷。5、圆刀/直刀纵切，被动吹废边自动装配。

Uses:

Surface winding slitting and rewinding machine is suitable for narrow strip rewinding such as aluminum foil, paper, insulating material, bronzing♈ film, plastic film (BOPP, PET, PE, PVC).

Features:

1. Unwinding is equipped with photoelectric automatic correction deviꦍce and magnetic powder brake automatic tension

2, equipped with a🃏utomatic metering, automatic shutdown device

3, the host frequency control

4. The two magnetic🐻 powder clutches and the main engine linkage control center are wound up and used in contact with the surface, and the two-axis cross winding is performed, never biting.

5. Round knife / straight knife slitting, automatic blowing waste side dev𓆉ice.
